STANDARD FEATURES
- Manufactured in USA
- Tray application only
- Suitable tight curve layout application for trays
- UHMW guide blocks and corner wheels direct the travel of the Polycord Belt
- All 304 stainless steel construction with a #4 finish
- Table top is constructed from 14 gauge stainless steel
- Low maintenance and sanitary design
- Easy belt wipe clean without the need of belt wash chamber / under table drip pans
- Adjustable speed control in NEMA 4 control cabinet with programmable AC inverter
- In-line or end drive unit configurations available to suit layout requirement
- Unit supported on 1-5/8” diameter 16 gauge wall polished stainless steel tubular legs with fully welded 1-5/8” cross bracing
- Cord is 1/2" mm in diameter
- Polycord weld kit included
- Smooth operation with low amp draw
1 Year Parts & Labor Warranty
Custom Field
bullet_point Dual ½ in. round polycord belt
bullet_point Used for conveying trays
bullet_point Sanitary design easy to clean
bullet_point Drive unit can be installed at the end of conveyor or inline anywhere along the length of the conveyor
bullet_point Polcord conveyor can be used for tray transfer above trough for assembly line style sorting/scrapping operation
bullet_point Can be supplied as a standalone unit or in combination with different conveyor models for an integrated custom soiledware handling system
bullet_point Contact factory for CAD / Revit models for all custom equipment
Resource - PDF - Spec Sheet https://store-b7r5ysvukn.mybigcommerce.com/content/spec-sheets/Dual-PolyCord-PCS2.pdf
Additional Information 1 Year Parts & Labor Warranty
Resource - Warranty Statement https://store-b7r5ysvukn.mybigcommerce.com/content/warranty/
